Thursday, February 9, 2012

Create PDF Report in Asp.Net Using iTextSharp




********************************************************************************


/*Add Stylesheet in your application names StyleSheet.css*/

body {}
.gridView{width:100%;background:#ffffff;border:1px solid #476db6; border-collapse:separate;}
.gridView th{border:0px;background:#a7b7fe;color:#000000;text-align:center;font-size:18px;}
.gridView td{border:0px;padding-left:10px;}
.gridView tr:hover{cursor:pointer; background:#ffff00;}
.gridView tr:last-child:hover{ background:#000;background:#a7b7fe;}
.altRow{background:#d1daff;}
.gridPager{background:#a7b7fe;color:#000000;}
.gridPager table{margin:0px auto;}
.gridPager table td{width:20px;}
.gridPager table span{cursor:pointer;font-weight:bold;color:#1a1ac9;}
.gridPager table a{cursor:pointer;text-decoration:none;color:#000000;}
.gridPager table a:hover{text-decoration:underline;}


********************************************************************************

<%@ Page Language="C#" AutoEventWireup="true" CodeFile="Default.aspx.cs" Inherits="_Default" %>

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<html xmlns="http://www.w3.org/1999/xhtml">
<head id="Head1" runat="server">
    <title>Create PDF Report in Asp.Net Using iTextSharp </title>
    <link href="StyleSheet.css" rel="stylesheet" type="text/css" />
</head>
<body>
    <form id="form1" runat="server">
    <div>
        <asp:Button ID="butPDF" runat="server" Text="Generate PDF" onclick="butPDF_Click" /><br />
        <a href="http://sourceforge.net/projects/itextsharp/">Download iTextsharp</a>
    </div>
    <div>
        <asp:GridView ID="GridView1"
        runat="server"
        AutoGenerateColumns="false"
        AllowSorting="true"
        CssClass="gridView"
        AlternatingRowStyle-CssClass="altRow"
        PagerStyle-CssClass="gridPager">
        <Columns>
            <asp:BoundField DataField="Productid" HeaderText="Product Id"/>
            <asp:BoundField DataField="Productname" HeaderText="Product"/>
            <asp:BoundField DataField="Productdetails" HeaderText="Details"/>
            <asp:BoundField DataField="Unitprice" HeaderText="Price" />
        </Columns>
        </asp:GridView>
    </div>
    </form>
</body>
</html>

*********************************************************************************

using System;
using System.IO;
using System.Web;
using System.Web.UI.WebControls;
using PDF = iTextSharp.text.pdf;
using PDFDoc = iTextSharp.text;

public partial class _Default : System.Web.UI.Page
{
    protected void Page_Load(object sender, EventArgs e)
    {
        if (!IsPostBack)
        {
            Products products = new Products();
            GridView1.DataSource = products.ReadAll();
            GridView1.DataBind();
        }
    }

    protected void butPDF_Click(object sender, EventArgs e)
    {
        PDFReport("Computers & Related Products", GridView1, "pdf1");
    }

    /// <summary>
    /// Create PDF
    /// </summary>
    /// <param name="heading"></param>
    /// <param name="grid"></param>
    /// <param name="reportName"></param>
    public void PDFReport(String heading, GridView grid, String reportName)
    {
        Int32 columns = grid.Columns.Count;

        MemoryStream ms = new MemoryStream();
        PDFDoc.Document document = new PDFDoc.Document();

        PDF.PdfWriter.GetInstance(document, ms);
        PDFDoc.Font font = new PDFDoc.Font(PDFDoc.Font.FontFamily.TIMES_ROMAN, 10, 0, new PDFDoc.BaseColor(0, 0, 0));
        PDFDoc.Font hfont = new PDFDoc.Font(PDFDoc.Font.FontFamily.TIMES_ROMAN, 15, 0, new PDFDoc.BaseColor(0, 0, 0));
        document.Open();
        PDF.PdfPTable table = new PDF.PdfPTable(columns);//No. of columns.

        //float[] widths = new float[] { 5f, 5f, 5f, 5f, 5f, 5f,5f,5f,5f };
        //table.SetWidths(widths);
        table.WidthPercentage = 100;//Width in persentage.

        //Create Header
        PDF.PdfPTable header = new PDF.PdfPTable(1);
        PDF.PdfPCell cell = new PDF.PdfPCell(new PDFDoc.Phrase(heading, hfont));//Report Head.
        cell.HorizontalAlignment = 1;//0=Left, 1=Centre, 2=Right
        cell.Border = 0;
        header.WidthPercentage = 100;
        header.AddCell(cell);
        document.Add(header);
        document.Add(new PDFDoc.Phrase("\n"));//Enter new line


        PDFDoc.Chunk reportCreationDate = new PDFDoc.Chunk(String.Format("Report Date : {0}", DateTime.Now), font);
        document.Add(reportCreationDate);
        document.Add(new PDFDoc.Phrase("\n"));//Enter new line

        // Custumer Name
        PDF.PdfPTable info = new PDF.PdfPTable(2);
        info.WidthPercentage = 100;
        PDF.PdfPCell Ccell = new PDF.PdfPCell(new PDFDoc.Phrase(String.Format("Customer : {0}", "Kaushik Mistry"), font));
        Ccell.Border = 0;
        Ccell.HorizontalAlignment = 0;
        info.AddCell(Ccell);
        PDF.PdfPCell DGcell = new PDF.PdfPCell(new PDFDoc.Phrase(String.Format("Durable goods report : {0}", "Computers & Related Products"), font));
        DGcell.Border = 0;
        DGcell.HorizontalAlignment = 2;
        info.AddCell(DGcell);
        document.Add(info);


        //Create Line
        PDF.PdfPTable line = new PDF.PdfPTable(1);

        //Report Head.
        PDF.PdfPCell lcell = new PDF.PdfPCell(new PDFDoc.Phrase(""));
        lcell.BorderWidthTop = 0;
        lcell.BorderWidthLeft = 0;
        lcell.BorderWidthRight = 0;
        lcell.BorderWidthBottom = 1;
        line.WidthPercentage = 100;
        line.AddCell(lcell);
        document.Add(line);

        document.Add(new PDFDoc.Phrase("\n"));//Enter new line

        for (Int32 i = 0; i <= 1; )
        {
            for (Int32 j = 0; j <= grid.Columns.Count - 1; j++)
            {
                PDF.PdfPCell _cell = new PDF.PdfPCell(new PDFDoc.Phrase(HttpUtility.HtmlDecode(grid.Columns[j].ToString()), font));
                _cell.BackgroundColor = new PDFDoc.BaseColor(245, 245, 245);//Background color of cell in RGB.
                _cell.HorizontalAlignment = 1;//0=Left, 1=Centre, 2=Right
                table.AddCell(_cell);
            }
            break;
        }

        for (Int32 i = 0; i <= grid.Rows.Count - 1; i++)
        {
            for (Int32 j = 0; j <= grid.Columns.Count - 1; j++)
            {
                PDF.PdfPCell _cell = new PDF.PdfPCell(new PDFDoc.Phrase(HttpUtility.HtmlDecode(grid.Rows[i].Cells[j].Text), font));
                _cell.HorizontalAlignment = 1;//0=Left, 1=Centre, 2=Right
                table.AddCell(_cell);
            }
        }

        document.Add(table);
        document.Close();

        Response.ContentType = "application/pdf";
        Response.AddHeader("content-disposition", String.Format("attachment;filename=Report-{0}.pdf", reportName));
        Response.Buffer = true;
        Response.OutputStream.Write(ms.GetBuffer(), 0, ms.GetBuffer().Length);
        Response.OutputStream.Flush();
        Response.End();
        Response.Clear();
    }
}

********************************************************************************

using System;
using System.Web.Configuration;
public class Connection
{
public Connection(){}
     /// <summary>
     /// Get Connection string.
     /// <summary>
  public static String Cs
    {
        get
        {
            return WebConfigurationManager.ConnectionStrings["cs"].ConnectionString;
        }
    }
}

********************************************************************************

#region Namespaces
using System;
using System.Collections.Generic;
using System.Data;
using System.Data.SqlClient;

#endregion

/// <summary>
/// class Products
/// </summary>
 public class Products
 {
#region Properties
      private Int32 _Productid;
     /// <summary>
     ///Gets or Sets the Int32 value of Productid
     /// </summary>
      public Int32 Productid { get { return _Productid;} set { _Productid = value;} }

      private String _Productname;
     /// <summary>
     ///Gets or Sets the String value of Productname
     /// </summary>
      public String Productname { get { return _Productname;} set { _Productname = value;} }

      private String _Productdetails;
     /// <summary>
     ///Gets or Sets the String value of Productdetails
     /// </summary>
      public String Productdetails { get { return _Productdetails;} set { _Productdetails = value;} }

      private Decimal _Unitprice;
     /// <summary>
     ///Gets or Sets the Decimal value of Unitprice
     /// </summary>
      public Decimal Unitprice { get { return _Unitprice;} set { _Unitprice = value;} }

      private Int32 _Quantity;
     /// <summary>
     ///Gets or Sets the Int32 value of Quantity
     /// </summary>
      public Int32 Quantity { get { return _Quantity;} set { _Quantity = value;} }

#endregion

#region Private Meambers
      private SqlCommand cmd;
      private SqlConnection con;
      private SqlDataReader table;
      private String ConnectionString = String.Empty;
#endregion

#region Constructor
     /// <summary>
     ///Default constructor
     /// </summary>
      public Products()
      {
        ConnectionString=Connection.Cs;
      }

     /// <summary>
     ///Parameterised constructor
     /// </summary>
      public Products(String connectionString)
      {
        ConnectionString=connectionString;
      }
#endregion

#region Public Methods

     /// <summary>
     /// This meathod returns all records of Products table.
     /// </summary>
     /// <returns> All rows of Products table.</returns>

      public List<Products> ReadAll()
       {
        using(con = new SqlConnection(ConnectionString))
         {
          try
           {
            List<Products> list = new List<Products>();
            if (con.State == ConnectionState.Closed)
            {
             con.Open();
            }
            cmd = new SqlCommand("Select Top(1000)* From [dbo].[Products]",con);
            using(table = cmd.ExecuteReader())
             {
              while (table.Read())
               {
                Products obj = new Products();
                obj._Productid = table.GetInt32(0);
                obj._Productname = table.GetString(1);
                obj._Productdetails = table.GetString(2);
                obj._Unitprice = table.GetDecimal(3);
                obj._Quantity = table.GetInt32(4);
                list.Add(obj);
               }
               //return (list.Count > 0) ? list : GetEmptyList(list);
               return list;
              }
             }
           finally
            {
              if (con.State == ConnectionState.Open)
               {
                con.Close();
               }
            }
         }
      }
#endregion

 }

********************************************************************************
<add name="cs" connectionString="Data Source=Your Data Source;Initial Catalog=softwarekaffee;Persist Security Info=True;User ID=Your User Id;Password=Your Password"/>
</connectionStrings>

********************************************************************************


Go
create database SoftwareKaffee

Go
use SoftwareKaffee

Go
Create table Products
(
    ProductId int identity primary key,
    ProductName varchar(50),
    ProductDetails nvarchar(200),
    UnitPrice decimal(7,2),
    Quantity int
)

Go
insert into Products values('Dell Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',55000,4)
insert into Products values( 'HCL Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',15000,30 )
insert into Products values( 'HP Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB', 23000 ,4 )
insert into Products values( 'HCL Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',35000,20 )
insert into Products values( 'Linovo Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 2GB',25000,30 )
insert into Products values( 'Copac Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',30000,30 )
insert into Products values( 'Dell Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',45000,10 )
insert into Products values( 'HP Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',55000,30 )
insert into Products values( 'HCL Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 2GB',35000,20 )
insert into Products values( 'Linovo Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',25000,30 )
insert into Products values( 'Copac Laptop','Processor Intel(R) Cort(T) i5 CPU, Ra 4GB',30000,60 )
insert into Products values( 'Dell Laptop','Processor Intel(R) Cort(T) i3 CPU, Ra 2GB',35000,30 )
insert into Products values( 'HP Laptop','Processor Intel(R) Cort(T) i3 CPU, Ra 2GB',55000,30 )
insert into Products values( 'HCL Laptop','Processor Intel(R) Cort(T) i3 CPU, Ra 2GB',34000,20 )
insert into Products values( 'Linovo Laptop','Processor Intel(R) Cort(T) i3 CPU, Ra 2GB',35000,30 )
insert into Products values( 'Copac Laptop','Processor Intel(R) Cort(T) i3 CPU, Ra 2GB',40000,30 )
insert into Products values( 'Dell Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',65000,30 )
insert into Products values( 'HP Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',75000,1 )
insert into Products values( 'HCL Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',45000,30 )
insert into Products values( 'Linovo Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',45000,30 )
insert into Products values( 'Copac Laptop','Processor Intel(RR) Cort(T2) i7 CPU, Ra 8GB',37000,5 )
